Marin Four Corners Special Edition Black
$95.99
- Discover a world of quality products.
- The Quality Choice for Smart Shoppers
- Multiple safe payment methods
- Uncompromising quality, every time.
The Four Corners series is perfectly suited to today’s commute and tomorrow’s touring adventures.
Five frame sizes
The Four Corners is available in five frame sizes to fit riders 4’11 to 6’4” without compromise. For proper fit and bike handling sizes XS and S use 650B wheels, sizes M, L, and XL use 700C.
Bottle / Gear mounts
New for 2021 are fork leg bottle or accessory cage mounts, along with traditional front triangle bottle mounts (three on sizes M-XL, two on XS-S) for up to six bottle cage mounts total.
Fender / rack mounts
The Four Corners has separate fender and rack mounts on both the frame and fork to fit a variety of aftermarket accessories securely and without interference with one another.
Steel is real
The Four Corners uses a double butted and formed 4130 CrMo frame specially tuned for loaded touring with upright geometry for comfortable and efficient all-day rides.
Disc brakes
Disc brakes provide smooth, controlled stopping in all conditions with minimal maintenance.
Details
- Weight specification for 46.2 cm frame variant
- Bracket for mudguards and luggage rack
- Spyre-C road disc brake
- Shimano Sora groupset
- Pedals included:
NoFind compatible pedals
Show all models from the Marin Four Corners series
The delivered product may have been produced earlier than the advertised model year.
Purpose
Gravel
The delivered product may have been produced earlier than the advertised model year.
Gender
Men, Women
The delivered product may have been produced earlier than the advertised model year.
Main Information
Total number of gears:
27
Type:
Not an e-bike
The delivered product may have been produced earlier than the advertised model year.
Frame
System:
Gravel
Frame material:
Steel
further specifications:
Utilitour double-butted CrMo, biometric geometry
The delivered product may have been produced earlier than the advertised model year.
Scope of Delivery
Includes pedals:
No
The delivered product may have been produced earlier than the advertised model year.
Dimensions
Weight:
13.23 kg
Maximum permissible weight limit:
120 kg
The delivered product may have been produced earlier than the advertised model year.
Fork
System:
Rigid fork
Type:
Eyelets for mudguard, luggage rack and bottle holder, IS brake mount
Material:
4130 Cr-Mo
The delivered product may have been produced earlier than the advertised model year.
Shifting Components
Drivetrain type:
Derailleur
Gear No.:
9
Brand:
Shimano
Type:
Sora
The delivered product may have been produced earlier than the advertised model year.
Front Derailleur
Version:
3-speed
Model:
Shimano Sora
The delivered product may have been produced earlier than the advertised model year.
Shift Levers
Model:
Shimano Sora SORA ST-R3000/3030
The delivered product may have been produced earlier than the advertised model year.
Chainset
Model:
Shimano Sora, FC-R3030, 170 mm
Sprocket 1:
50 teeth
Sprocket 2:
39 teeth
Sprocket 3:
30 teeth
The delivered product may have been produced earlier than the advertised model year.
Bottom Bracket
Model:
Shimano Hollowtech II
The delivered product may have been produced earlier than the advertised model year.
Chain
Model:
KMC X9
The delivered product may have been produced earlier than the advertised model year.
Cassette
Sprocket Gear Ratio (teeth):
11-34 teeth
Model:
Shimano HG200-9
The delivered product may have been produced earlier than the advertised model year.
Front Brakes
Brand:
Tektro
Type:
Spyre-C Road
Brake system:
Mechanical disc brake
Front Brake Rotor:
Tektro TR
disc diameter:
160 mm
The delivered product may have been produced earlier than the advertised model year.
Rear Brakes
Brand:
Tektro
Type:
Spyre-C Road
Brake system:
Mechanical disc brake
Rear Brake Rotor:
Tektro TR
disc diameter:
160 mm
The delivered product may have been produced earlier than the advertised model year.
Handlebars
System:
Bockstyre
Model:
Trans-X, RA48A, aluminium 6061-T6, 400 mm wide, 0 rise, 70 mm reach, 120 mm drop, 31.8 mm
Material:
Aluminium
Bar tape:
VELO VLT-049-01
The delivered product may have been produced earlier than the advertised model year.
Stem
System:
A-Head
Model:
Hsin Lung TDS-D507G-8FOV, 70 mm, 7°, 1-1/8″, 31.8 mm
Material:
Aluminium
The delivered product may have been produced earlier than the advertised model year.
Headset
Head Set:
FSA Orbit CE NO.8B, 42/42,1-1/8″
The delivered product may have been produced earlier than the advertised model year.
Saddle
Saddle:
Velo VL-1353
The delivered product may have been produced earlier than the advertised model year.
Seatpost
System:
integrated seatpost
Diameter:
27.2 mm
Type:
Hsin Lung SPC255, 350 mm, 15 mm offset
Material:
Aluminium
The delivered product may have been produced earlier than the advertised model year.
Front Hub
Model:
Joytech D761DSE, 6 hole, 9 x 100 mm
The delivered product may have been produced earlier than the advertised model year.
Rear Hub
Model:
Joytech D762TSE, 6-hole, 10 x 135 mm
The delivered product may have been produced earlier than the advertised model year.
Rims
Model:
Jalco JD200, 32-hole
Material:
Aluminium
System:
double wall
Size (In Inches):
27.5 inches
The delivered product may have been produced earlier than the advertised model year.
Spokes
Spokes:
14g, black stainless steel
The delivered product may have been produced earlier than the advertised model year.
Front Tyre
Tire width:
42 mm
Model:
WTB Resolute, Puncture Protection (Size XS/S: 27.5″; Size M/L/XL: 28″)
The delivered product may have been produced earlier than the advertised model year.
Rear Tyre
Tire width:
42 mm
Model:
WTB Resolute, Puncture Protection (Size XS/S: 27.5″; Size M/L/XL: 28″)
The delivered product may have been produced earlier than the advertised model year.
Equipment
Pedals:
Touring flat pedals
The delivered product may have been produced earlier than the advertised model year.
Model Year
2022
The delivered product may have been produced earlier than the advertised model year.
Article number
1732787
| Choose Frame size | 38,1cm (27.5"), 42,2cm (27.5"), 46,2cm (28"), 49,5cm (28"), 52,8cm (28") |
|---|
